TJ Series Plastic Enclosure Big Switch Box(Screw Type)

Material : ABS, PC

Colour : Gray

Protection degree : IP66

Working temperature : -40˚C to +120˚C

Feature :

Durable and Rugged Design. The enclosure is according to EN60529 standard free from corrosion compressive property and insulation, widely used in electronics communications, fire fighting apparatus, control panels, terminal boxes, public accommodation, ship industry, food industry etc.

Screw Type		Dimension(mm.)		Mounting Plate		Installation Size(mm.)
Grey Door	Clear Door	W x H x D	D1 + D2	Plastic	Metal	W3	H3
TJ-AG-2819	TJ-AT-2819	280x190x130	98+32	TJ-2819P	TJ-2819	255	165
TJ-AG-2819-1	TJ-AT-2819-1	280x190x180	98+32	TJ-2819P	TJ-2819	255	165
TJ-AG-2819-2	TJ-AT-2819-2	280x190x180	148+32	TJ-2819P	TJ-2819	255	165
TJ-AG-2819-3	TJ-AT-2819-3	280x190x230	148+82	TJ-2819P	TJ-2819	255	165
TJ-AG-2828	TJ-AT-2828	280x280x160	98+31	TJ-2828P	TJ-2828	255	255
TJ-AG-2828-1	TJ-AT-2828-1	280x280x190	98+31	TJ-2828P	TJ-2828	255	255
TJ-AG-2828-2	TJ-AT-2828-2	280x280x180	148+32	TJ-2828P	TJ-2828	255	255
TJ-AG-2828-3	TJ-AT-2808-3	280x28xx230	148+81	TJ-2828P	TJ-2825	255	255
TJ-AG-3428	TJ-AT-3428	340x280x130	98+32	TJ-3428P	TJ-3428	315	255
TJ-AG-3428-1	TJ-AT-3428-1	340x280x180	98+81	TJ-3428P	TJ-3428	355	355
TJ-AG-3819-S	TJ-AT-3819-S	380x190x100	69+30	TJ-3819P	TJ-3819	355	165
TJ-AG-3819	TJ-AT-3819	380x190x130	98+30	TJ-3819P	TJ-3819	355	165
TJ-AG-3819-1	TJ-AT-3819-1	380x190x180	148+30	TJ-3819P	TJ-3819	355	165
TJ-AG-3828	TJ-AT-3828	380x280x130	98+32	TJ-3828P	TJ-3828	355	255
TJ-AG-3828-1	TJ-AT-3828-1	380x280x180	98+82	TJ-3828P	TJ-3828	355	255
TJ-AG-3828-2	TJ-AT-3838-2	380x280x180	148+32	TJ-3828P	TJ-3828	355	255
TJ-AG-3828-3	TJ-AT-3828-3	380x280x230	148+82	TJ-2828PX2	TJ-3828	355	255
TJ-AG-2856	TJ-AT-2856	280x560x130	98+32	TJ-2828PX2	TJ-2856	540	255
TJ-AG-3856	TJ-AT-3856	380x560x180	148+32	TJ-3828PX2	TJ-3856	534	354
